path

SEQUENTIAL SWITCH

PATH is a two channel 4:1 or one channel 8:1 sequential switch. You can use the switch in both directions meaning you either have four inputs and one output, or one input and four outputs. 5V is normalized to the COM I/O (bottom jack) so that it can be used as a gate/trigger sequencer. The switches can be cycled through with triggers or are addressable via CV.

Technical Specs

CURRENT DRAW:

  • +12V:   108mA
  • -12V:   0mA
  • +5V:    0mA

DIMENSIONS:

  • WIDTH:   6HP
  • DEPTH:   20mm

BUILD DIFFICULTY: MEDIUM

  • difficulty
    Firmware upload via programmer required
  • difficulty
    Densely populated board
  • difficulty
    Small IC packages

RESOURCES
