tune

VCO TUNER

TUNE is a frequency counter at heart, perfect to find the pitch of regular VCO waveforms. It has two display modes, -1 octave square and through output modes selectable and it supports A440Hz and A432Hz tuning systems.

Technical Specs

CURRENT DRAW:

  • +12V:   46mA
  • -12V:   4mA
  • +5V:    0mA

DIMENSIONS:

  • WIDTH:   2HP
  • DEPTH:   42mm

BUILD DIFFICULTY: MEDIUM

  • difficulty
    Firmware upload via programmer required
  • difficulty
    Multiple PCBs
  • difficulty
    Small IC packages
